新型MSP
工具不要のワンタッチ着脱を実現「新型MSP」
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-9.png)
製品スペック
材質 A502
枠寸法 650×550×10㎜
枠サイズ カスタム可能
取付方法
ボタンを押すだけ簡単装着!
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-14.png)
作業時間が従来品より85%短縮!!
MSP:120秒
・ネジを8か所取り付け
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-15.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-16-1.png)
ベースフレーム25㎜・メインフレーム5㎜
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-17-1.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-18.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-19.png)
新型MSP:15秒
・スイッチを4か所取付
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-20.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-16-1.png)
ベースフレーム30㎜・メインフレーム10㎜
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-17-1.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-21.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-22.png)
着脱式フレーム:15秒
・エアーを供給
・カバーを4か所取付
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-23.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-24.png)
ベースフレーム30㎜・メインフレーム10㎜
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-17-1.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-25.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-19.png)
新型MSPはこんな方にオススメ!
疾風 -hayate-
メタルマスク保管スペース削減 着脱式メタルマスク
メイコーメカトロニクス事業との連携により、従来のアルミフレーム方式から着脱できるフレームの開発に成功。これにより省スペースと低コストを実現いたしました!
お客様の声
・メタルマスクの保管場所がなく困っている。 → 従来の1/8に削減可能!
・実装のイニシャル費を少しでも安くしたい。 → 従来タイプに比べ20%のコストダウン!
※当社比
特徴
![疾風](https://meiko-techno.com/metalmask/wp-content/uploads/2022/07/hayate.png)
省スペース
専用保管箱でコンパクト収納。管理も容易です。
テンション
独自の構造により長時間安定したテンションを維持。また、作業者によるバラツキもありません。
作業性
ワンタッチで簡単着脱。段取替え時間ロスを可能な限り低減しました。
コスト
コンビネーション工程を廃止することで従来仕様のメタルマスクに比べ低価格にてご提供させていただきます。※当社比
Before
![枠保管スペース](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-2.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-1.png)
After
![枠保管省スペース](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-3.png)
こんなに省スペースになりました!
MSP
メタルマスク保管スペース削減 省スペースアルミ枠
![MSP アルミ枠](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-4.png)
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/07/MSP.png)
仕様
特徴 省スペースアルミ枠
テンション 通常アルミと同等
材質 A502
省スペース 1版あたり5㎜
通常在庫枠寸法 736×736×10 ・ 650×550×5 ・ 600×500×5
作業性 従来通りの取り扱い / ビス止め作業 1回60秒
基本情報
650×550×5㎜
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-6.png)
650×550×5㎜
![](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-7.png)
取り付け方法
①乗せる
②ビス止め
![基板面側、スキージ面側・サブフレーム5㎜、メインフレーム25㎜](https://meiko-techno.com/metalmask/wp-content/uploads/2022/04/waku-0.png)
